BAFFLE TYPE

            GREASE FILTERS





baffle filters

ftp://ftp.trinecorp.com/public/trine_logo.gif

Trine is proudly owned by Harloff Manufacturing Company


Visit us at www.hmcmi.com





baffle filters baffle filters

  ALUMINUM

GALVANIZED

STAINLESS STEEL

   SIZE

ITEM #

WEIGHT/LBS

ITEM #

WEIGHT/LBS

ITEM #

WEIGHT/LBS

10 x 16

T30K 2 T35K 2-1/2 T50K 2-1/2

12 x 16

T30G 2-1/8 T35G 3 T50G 3-1/2
16 x 16 T30 2-1/2 T35 4 T50 4
20 x 16 T30I 3 T35I 4-1/2 T50I 4-1/2
25 x 16 T30J 3-3/4 T35J 5 T50J 6

10 x 20 T30F 2-1/4 T35F 3-1/2 T50F 3-1/2
12 x 20 T30H 2-1/2 T35H 4 T50H 4
16 x 20 T30A 3-1/4 T35A 5 T50A 5
20 x 20 T30B 4 T35B 6 T50B 6
25 x 20 T30C 4-1/2 T35C 7 T50C 7-1/2
10 x 25 T30L 2-3/4 T35L 4 T50L 4-1/2
12 x 25 T30M 3 T35M 5 T50M 4-1/2
16 x 25 T30D 3-3/4 T35D 5-1/2 T50D 6
20 x 25 T30E 4-1/2 T35E 6-1/2 T50E 7






ACCEPTED FOR USE BY CITY OF NEW YORK DEPARTMENT OF BUILDINGS MEA 142 - 05 - E AND NSF CERTIFIED



ALUMINUM - LIGHTWEIGHT FOR EASE OF HANDLING



STAINLESS STEEL -FOR TOUGH COMMERCIAL APPLICATION AND
MAXIMUM PERMANENT PROTECTION AGAINST RUST AND CORROSION



GALVANIZED STEEL - FOR STRONG RUGGED PERFORMANCE, SUPERB
CORROSION RESISTANCE AND ABSOLUTE LOW COST



SAFE, DEPENDABLE, POSITIVE FLAME BARRIER PROTECTION



SEAMLESS, SMOOTH SURFACES PERMIT CONSTANT GREASE
RUN-OFF INTO HOOD COLLECTION TROUGHS...EASILY CLEANED
BY SOAKING, SPRAYING OR IN CONVENTIONAL DISHWASHER

DESIGNED TO REPLACE MESH FILTERS WITHOUT COSTLY HOOD MODIFICATIONS. ALSO AVAILABLE LOCKING HANDLES FOR ALL

SIZES.



CALL FOR PRICING @ (269) 655 1097
